FIRE BRICKS

Fire Bricks

MHD / HHD Bricks :(30 - 32% / 38 - 40% Alumina )


These are general - purpose firebricks made from selected grades of raw and calcined fire clay and fired to suit the customer's application.

Superduty Bricks :(43 - 45% Alumina)

Superduty bricks are made from a combination of superior grades of calcined clays and calcined kyanite. Very pure, low porosity bricks with exceptional hot strength suggested for glass regenerator and steel making applications.

Bauxite Based Bricks: (45-80% Alumina)

Mani, factured from calcined indigenous / imported bauxite. These bricks are the most economical solution in their alumina class. Especially noteworthy are the 70% to 80% Alumina class which has proven their nerve in steel ladles and cement rotary kilns.

Sillimanite : (58-60% Alumina)

This is by far the most versatile range of high alumina refractory shapes & straigth Vindyawasini Refractories portfolio. Extra pure dense grades with very high mullite Content are ideal solutions for Glass plant, Blast furnace Stove and stack and other demanding applications a where as Dutta Co - SILL is the economical low iron alternative for applications up to 1700°C.

Fire Bricks Product Specification:

Brand Name Al2O3
(%) Min
Fe2O3
(%) Max
A.P
(%) Max
B.D
(gm/cc) Min
CCS
(kg/cm) Min
PLC
(%) Max
PCE
(SK) Min
RUL.ta
(0C) Min
Aplication Area
DC-36 36 1.7 18 2.15 300 ±0.30 at 1450°C/2hrs 31 1450 Blast Furnace Stack Lining
DC-42 42 1.5 16 2.25 400 ±0.50 at 1450°C/2hrs 33 1500 Blast Furnace Lining
DC45 45 1.5 21 2.20 350 ±0.50 at 1500°C/2hrs 34 1450 Blast Furnace Lining cement rotary kiln, lime calcination kiln, glass tank furnace
DC-45A 45 1.5 16 2.30 450 ±0.30 at 1450°C/2hrs 34 1500 do
DC-50 50 1.3 18 2.35 350 ±0.30 at 1500°C/2hrs 34 1530 Anode baking furnace
DC--HA-59 59 1.2 18 2.50 500 ±0.50 at 1500°C/2hrs 36 1600 BF hot blast main, glass tank furnace
DC-HA-50 50 1.1 18 2.40 400 ±0.50 at 1500°C/2hrs 34 1520 Anode baking furnace
DC-45B 45 3.5 22 2.25 300 ±1.5 at 1350°C/2hrs 33 1350 Cement plants
DC-50A 50 3.5 22 2.30 350 ±1.5 at 1400°C/2hrs 33 1370 do
DC-60 60 2.5 22 2.54 450 ±2.0 at 1450°C/2hrs 35 1420
DC-60A 60 3 22 2.40 400 do 34 1400
DC-60 62 1.5 22 2.40 350 ±0.40 at 1500°C/2hrs 36 1500 Blast furness stove checkers
DC-60A 62 1.2 16 2.50 600 ±0.20 at 1500°C/2hrs 36 1550 Blast furness health & tuyere
DC-60B 62 1.2 18 2.52 500 ±0.30 at 1500°C/2hrs 36 1600 Blast furness  checkers
DC-70 EAF 70 2.5 20 2.60 500 ±3.0 at 1600°C/2hrs 36 1480 EAF roof ladle
DC-70A EAF 70 3 22 2.55 450 ±3.0 at 1450°C/2hrs 36 1440 EAF roof ladle
DC-80 EAF 80 2.5 20 2.70 500 ±3.0 at 1600°C/2hrs 37 1500 do
DC-80A EAF 80 3 22 2.70 500 ±3.0 at 1450°C/2hrs 35 1480 do
